Environment variables in alphabetical order

C

CASRDO44_NEWSUB

Category: General

Enables access to JCL files held on the local machine on which the browser is running.

Syntax

CASRDO44_NEWSUB=Value
export CASRDO44_NEWSUB

Values

ON
Access JCL files on the local machine on which the browser is running.
OFF
Access JCL files from the machine running the enterprise server.

CASSPOOL_LOCK_RETRY_COUNT

Category: JES

If errors are experienced by the spool module, the number of times it retries to obtain a record lock can be adjusted using this environment variable.

Syntax

CASSPOOL_LOCK_RETRY_COUNT=count
export CASSPOOL_LOCK_RETRY_COUNT

Values

count The number of retries made to obtain a record lock.

Default

If not specified, this variable defaults to 20.

CCITIMEOUT

Allows the specification, in tenths of seconds, of the maximum time out period that will be used with any LSC style application, such as Drag and Drop, SourceConnect, or the Monitor. The maximum value that can be used is 2,147,483,647.

Syntax

CCITIMEOUT=value}
export CCITIMEOUT

Default

The default is 1200 (2 minutes).

Example

This example sets the value to 4 minutes:

SET CCITIMEOUT=2400

CCIERRLOG

Specifies the output location and filename of ccierr.log content which tracks first-instance errors reported from the operating systems. CCIERRLOG overrides any entries found in CCI.INI, where the syntax and content is explained in detail.

CCITCP2

Instead of using the CCI Configuration Utility to set the TCP address of the machine running the CCITCP2 registration daemon the environment variable "CCITCP2" can be used instead. This may be useful if you need different processes on the same machine to contact different registration daemons.

Syntax

CCITCP2=hostname
export CCITCP2

Parameters

hostname is the TCP hostname or dotted decimal IP address of the machine running the CCITCP2 daemon you wish to contact from that session.

Comments

The environment variable value will always take precedence over any value set using the Configuration Utility. To restore a process to using the value set by the Configuration Utility simply set the environment variable to an empty string, such as

set CCITCP2=

Alternatively, if this environment variable is set system-wide (by creating a system variable in the system environment settings, or by using a CONFIG.SYS file) then this value will always take precedence over any value set using the Configuration Utility.

CCITCP2_PORT

The port that is being used for the registration process.

Syntax

CCITCP2_PORT=port
export CCITCP2_PORT

Parameters

port The port on which the CCITCP2 registration program operates.

CCITCPS

To start a CCI server on a fixed port, you can associate the Server Name with the port value by using the CCITCPS_ environment variable instead of appending the information on the Server Name itself.

Syntax

CCITCPS_server_name=port
export CCITCPS

Parameters

server_name is the name of the CCI server
port is the fixed TCP post to use

Note that this will only work if the server application process is started in the same session or process that has this environment variable set.

Example

set CCITCPS_server_name=MFPORT:3000
export CCITCPS

CCITCPT

If a client is known to be trying to connect to a server with Server Name server_name, and the TCP address and port (e.g. 3000) that the server is using is known, then the client can be made to connect directly to it by setting this environment variable.

Syntax

CCITCPT_server_name=MFNODE:server_hostname,MFPORT:port_number

Note that this can be used instead of setting the client Machine Name value. This is useful if the Machine Name value the client specifies cannot be altered by an application defined method.

Parameters

server_name The server to which the client is trying to connect.
server_hostname The TCP address.
port_number The TCP post number.

Example

CCITCPT_server1=MFNODE:server2,MFPORT:3000

CCITRACE

Part of the process to enable CCI tracing is to specify the degree of information that will be traced, which can be done by setting the CCITRACE environment variable as follows:

Syntax

CCITRACE=filename [options]

Parameters

filename The name of the log file you want the trace output to go to. If you do not specify this parameter, the log file ccitrace.log is created in the current directory with all options set to their default states.
options Any, or all, of the following:

/F or -F	logs the details of CCI API calls to the trace file. The default is OFF, unless a `filename` any other trace option is specified, in which case it is always ON.
/P or -P	logs the details of protocol-level calls to the trace file. The default is OFF. If this flag is OFF, then only the details of the CCI user-level API will be traced. If this flag is ON, the level of function tracing may be greatly increased.
/D or -D	logs the contents of all buffers passed to and from the CCI functions. The default is OFF. Data tracing may not be allowed if the application has been coded to prohibit data tracing for security reasons.

So to create a CCI trace file with the default name of ccitrc1.trc (with matching ccitrc1.idx file) which traces CCI API function flow, along with the underlying protocol function flow, but with no tracing of the user data passed to these calls, the value of the CCITRACE environment variable would be /P.

The CCI.INI file can also be used to control trace options, but any values specified by the CCITRACE environment variable will take precedence.

CICS_SIT

The name of the SIT used by the region.

Values

The name of the SIT that the region uses.

COBAIF

Specifies the directory path that Animator is to search for the session (.aif) file for the program being animated, if it is not found in the same directory as the information (.idy) file. Animator can update the session file to record information held between sessions. The .aif file contains details of breakpoints and monitors.

Syntax

COBAIF=pathname
export COBAIF

Parameters

A list of search directories, each item separated by a colon. The path where the .aif files are located.

Comments

If the .aif file is not found in the directory specified, a search is made of the directories specified by the COBIDY environment variable. If the file is still not found, the current directory is searched.

If an .aif file does not exist, Animator creates it as follows:

If COBAIF is set, the .aif file is created in the first directory specified by COBAIF
If COBAIF is not set, the .aif file is created in the directory specified in the environment variable COBIDY from which the program .idy file was loaded
If COBAIF and COBIDY are not set, or if the first directory specified by COBIDY is not found, the .aif file is created in the current directory

COBAIFNAME

Specifies the basename of the Animator session file (.aif ) for the program being animated. The .aif file contains details of breakpoints and monitors.

Syntax

COBAIFNAME=basename
export COBAIFNAME

Parameters

Basename The basename of the .aif files.

Comments

You need to specify this environment variable if you are starting Animator using COBSW=+A and you want to save breakpoints for subsequent animation sessions. You can also specify it if you are starting Animator using the command anim; in this case the basename you specify overrides the application name as the basename of the .aif file.

COBANIMOPT

Specifies additional directives to be used by Character Animator.

Syntax

COBANIMOPT=directive-list
export COBANIMOPT

Parameters

directive-list A directive, or list of directives. Must not be a filename.

Comments

When you invoke Character Animator, it first reads the directives you have specified in COBANIMOPT and then uses any directives you specify in the command line (which might override some of the directives you set in COBANIMOPT).

Example

COBANIMOPT="MIXEDLANGDEBUG MULTITHREAD"
export COBANIMOPT

COBANIMSRV

Identifies which COBOL program a waiting Character Animator process should attach to.

Syntax

COBANIMSRV=progid
export COBANIMSRV

Parameters

progid An identifier that is used to identify the program to which Character Animator will attach.

Comments

This environment variable is particularly useful for starting cross-session debugging.

Example

In one console session:

export COBANIMSRV=myid

myid is now a unique identifier that you can use to match Character Animator to a program. Type the command to start Character Animator:

cobanimsrv

The Character Animator waits for a COBOL program to start that has a matching identifier. In another console session:

export COBANIMSRV=myid
cobrun prog1.int

When prog1.int starts, the unique identifier myid matches that of Character Animator; therefore, Character Animator attaches to this process. In console session 1, the Character Animator main screen is displayed and the cursor placed on the first line of prog1.int.

COBATTR

Specifies non-standard behavior for HIGHLIGHT and LOWLIGHT clauses used with ACCEPT and DISPLAY statements. It provides compatibility with earlier COBOL products. You should avoid using it wherever possible as support might be discontinued at some future date.

Syntax

COBATTR=n
export COBATTR

Parameters

n A value in the range 0 through 7. It can be one of the following values, or a cumulative value; for example, specifying a value of 6 would result in the behavior described for values 4 and 2.

0
Provides standard, default behavior.

When a COBOL program displays text subject to a HIGHLIGHT or LOWLIGHT clause, the run-time system uses respectively the bold or dim mode specified in the terminfo entry for the terminal. If the bold or dim mode is not specified, then the HIGHLIGHT or LOWLIGHT clause respectively has no effect.
1
When a COBOL program displays text subject to a HIGHLIGHT clause, the run-time system uses the bold mode. The run-time system uses the default mode for normal text. Specifying dim mode in the terminfo entry for the terminal has no affect. The LOWLIGHT clause has no effect.
2
High and low intensity space characters are not assumed to be the same as normal mode space characters.
3
As for 1 and 2 above
4
Provides compatibility with default behavior of products before COBOL version 3.2.

When a COBOL program displays text subject to a HIGHLIGHT clause, the effect depends on whether the dim mode is specified in the terminfo entry for the terminal. If dim mode is specified, then the run-time system uses the default mode for highlighted text and the dim mode for normal text. If the dim mode is not specified, then the run-time system uses the bold mode for highlighted text and default mode for normal text. The LOWLIGHT clause has no effect, giving the same appearance as normal text.

Example

COBATTR=1
export COBATTR

COBCONFIG

Specifies a run-time configuration file that tailors the run-time configurable options in some way.

Syntax

COBCONFIG=pathname
export COBCONFIG

Parameters

pathname The name of the COBOL configuration file that tailors the runtime

Comments

If $COBCONFIG is not set then the file $COBDIR/etc/cobconfig is searched for instead.

Example

COBCONFIG=/home/mydir/cobconfig
export COBCONFIG

COBCONFIGJVM

Specifies a Java properties file that tailors the run-time configurable options for Java Virtual Machine applications. Use this instead of COBCONFIG in COBOL applications intended for use on a Java Virtual Machine.

Values

The location of a properties file.

COBCONFIG.BLOCK

The location of the application configuration file.

COBCPY

Specifies the directory or directories that the Compiler and Animator should search for copyfiles.

Syntax

COBCPY=pathname[:pathname]...
export COBCPY

Parameters

pathname
A directory that the Compiler and Animator are to search when looking for copyfiles. When more than one pathname is present, a null pathname represents the current working directory.

Example

COBCPY=/home/group/sharedcopy::mydir/mycpy
export COBCPY

causes the Compiler to search for a copyfile in /home/group/sharedcopy, then in the current directory and finally in ./mydir/mycpy until either the copyfile is found or it can be considered not found.

COBDATA

Specifies one or more locations, separated by ; (Windows) or : (UNIX), in which to search for data files at run time. As long as the file assignment does not contain a sub-path (that is, a string containing \ or /) then the file assignment is appended to each location specified by COBDATA in order to locate the file.

Note: Users modernizing RM/COBOL or ACUCOBOL-GT legacy code can use a sub-path in the file assignment, but only by compiling with the relevant DIALECT or IDXFORMAT values for the respective File Handling systems; setting these values in the File Handling configuration file is not sufficient to achieve this.

Specifies the directory or directories that the run-time system is to search for data files. Provides you with the facility to map data files globally, thus enabling you to put working data files in a directory whose name is not known until run time.

Syntax

COBDATA=pathname[:pathname]...
export COBDATA

Parameters

A list of search directories, each item separated by a colon. The runtime system is to search these when looking for application data files. When more than one pathname is present, a null pathname represents the current working directory.

Comments

COBDATA affects the compiler and other utilities. During compilation, for example, program source is regarded as a data file by the compiler. If you intend to use any COBOL development system utilities, we recommend that the COBDATA value starts with a colon (:).

COBDATA is considered set if there is an environment variable of this name in your environment space, and its value is non-empty.

The full mapping order for files is:

Any dd_ environment mappings
Any ASSIGN TO EXTERNAL mappings
Any COBDATA environment variable mappings

For multiple directory paths specified either in the COBDATA environment variable or a dd_ environment variable, the system searches the first directory specified followed by a slash (/) as a prefix to the user name.

If the filename is not found, or is not readable, the search continues with the next directory until the final directory has been searched. If no file is found, the first directory is used if a file is to be created.

Any dd_ and COBDATA mappings are ignored for any filename that starts with a hyphen () or a slash (/). In addition, it is illegal to have a hyphen in an environment variable name.

When using this facility, you should not use a filename that starts with "COB... "(these are reserved for the COBOL system).

You can use the COBDATA environment variable for files open in any mode (including OUTPUT) and for fixed or variable length files. If you are using indexed files, both the data and index files must be in the same directory.

The COBDATA environment variable affects file deletes, using the rules given here, as well as file opens.

If you intend to use COBOL development system programs, we recommend that you first unset COBDATA, as many of these programs open data files and are thus affected by the value of COBDATA. If you have to set COBDATA, you should include the paths :$COBDIR/dynload/helptbox.lbr and :$COBDIR/dynload/check.lbr at the beginning of the COBDATA value. If you want to see the Animator Help pages, also include COBDIR/dynload/advanim.lbr.

Example

COBDATA=:demo:/home/data:progs
export COBDATA

causes COBDATA to be set to instruct the runtime system to search for data files in the current directory, then in the directory ./demo, then in the directory /home/data and finally in ./progs.

COBDIR

Specifies the directory where the required Micro Focus COBOL system is installed. Many of the COBOL system components and utilities require and use this information. If the COBDIR environment variable is not set then the COBOL system acts as if it had been set to the default COBOL system directory. This default directory is /opt/microfocus/VisualCOBOL on UNIX systems.

Syntax

COBDIR=pathname
export COBDIR

Parameters

pathname The directory that contains the required Micro Focus COBOL system software.

Comments

The Micro Focus COBOL system is normally installed in the default COBOL system directory and so does not require COBDIR to be set. COBDIR only needs to be set when your COBOL system has been installed in a different directory such as when more than one version of the COBOL system is available at the same time.

Example

COBDIR=/home/products/cobse20
export COBDIR

This causes the Cob utility to search the directory /home/products/cobse20 for the Micro Focus COBOL system software.

COBIDY

Specifies the directory that Animator is to search for the information (.idy) file for the program being animated if it is not found in the same directory as the intermediate code (.int) file. Animator can update the information file to record information held between sessions.

Syntax

COBIDY=pathname
export COBIDY

Parameters

pathname A list of search directories, each item separated by a colon.

COBJVM

Specifies which Java Virtual Machine (JVM) to load.

Syntax

COBJVM=platform_nnn
export COBJVM

Parameters

platform_nnn where

platform is a threecharacter code that indicates the platform on which you are running Server Express, for example:

ibm IBM AIX
unx SCO UnixWare
sun Oracle SPARC

nnn indicates the version of the JVM, for example:

122 Version 1.2.2
130 Version 1.3.0

Comments

You might need to set COBJVM if you are developing distributed applications with both COBOL and Java components.

Example

COBJVM=ibm_122
export COBJVM

COBKEYTIMEOUT

Specifies the maximum elapsed time, in tenths of a second, for the connected terminal to transmit any valid escape sequence to the runtime system.

When a terminal key is depressed, the terminal might send in response a single character or a group of characters to the runtime system. Typically, such a group of characters starts with an escape character and the group of characters is known as an escape sequence. A terminal might send an escape sequence for one depression of a function key. It might also send the same sequence of characters for a depression of the Escape key followed by the depression of one or more alphabetic or numeric data keys. The only difference apparent to the runtime system is the interval between the arrival of each character; the user cannot type as fast as the escape sequence is generated by the terminal.

If a terminal is connected over a network that sends the characters to the runtime system in discrete packets, then the network can alter the intervals between each character arriving at the runtime system. COBKEYTIMEOUT is available to help compensate for typical network delays so the runtime system identifies escape sequences correctly.

Syntax

COBKEYTIMEOUT=n
export COBKEYTIMEOUT

Parameters

n A number in the range 1 through 126 that represents the maximum elapsed time required for a terminal to transmit any valid escape sequence to the runtime system over the line or network connection. On encountering a lone Escape character, the runtime system waits n tenths of a second before assuming that the character does not introduce an escape sequence. The runtime system calculates an appropriate default value for n from the baud rate of the terminal.

COBLANG

The language environment in which your COBOL program runs.

Values

A COBOL language environment (LE) value.

COBLPFORM

This configuration variable is used to define and print to printer channels C01-C12. Specify the line numbers for each channel with the COBLPFORM configuration variable. Null entries are ignored. Those channels that have line number zero, function-names S01-S052, CSP, or are undefined, are set to line 1.

Example 1:

COBLPFORM 1:3:5:7:9:11:13:15:17:19:21:23

In this example C01 equals 1, C02 equals 3, and so on.

Example 2:

COBLPFORM :3::5: :9

In this example, C01 equals 3, C02 equals 5, C03 equals 1, and C04 equals 9. You can specify only a single line number for each channel.

In example 2 above, channels C05 - C12 are undefined. If a print statement specifies channel C05 - C12, the line is printed at line 1. In addition, in the example shown, C03 equals 1 because its value is a space and therefore undefined.

Any WRITE BEFORE/AFTER PAGE statements cause positioning to be at line 1. Each line advance increases the line number by one. A request to skip to a line number less than or equal to the current line causes a new page to begin. The appropriate number of line feeds are then generated.

COBMAINSTACK

Specifies the size of the main stack.

Syntax

COBMAINSTACK=n
export COBMAINSTACK

Parameters

n A number in the range 1 through nnn that represents the size of the main stack.

Comments

You might need to set COBMAINSTACK in any of the following circumstances:

If you are deploying OO COBOL Enterprise JavaBeans (EJBs) to WebSphere on the AIX platform
If you are using the multi-threaded run-time system

If you have IF STATEMENTS with a very large number of ELSE clauses

COBMODE

Whether to start the server in 32-bit or 64-bit mode.

Values

32
The system starts in 32-bit mode
64
The system starts in 64-bit mode

COBOPT

Specifies user default options to the Cob utility.

Syntax

COBOPT="[set environment-variable=value]
[options] ...
[cobextn: .ext [.ext] ... ]"
export COBOPT

COBOPT=[pathname/]filename
export COBOPT

Parameters

environment-variable Any one of the environment variables supported by the COBOL system and listed in this appendix.
value The value to which you want to set the specified environment variable.
options One or more cob command line options. See the chapter COBOL System Interface (cob) for details on the format of cob options.
.extA filename extension that, in addition to the standard ones of .cob, .CBL, or .cbl, denotes a file that Cob should treat as a COBOL source file. The extension must begin with a period, and if more than one is specified on one line then they must be separated by a space or tab character. You can use more than one cobextn line.
pathname The directory that the COBOL system is to search for an options file.
filename The name of a file containing cob options.

If a line does not begin with one of the identifiers set or cobextn: then it is taken as an options line.

Comments

COBOPT can either contain options that supplement or override the system default options defined in $COBDIR/etc/cobopt, or it can specify the path of a file that contains such options. The options can extend over more than one line and each line must have the same format as described for the file $COBDIR/etc/cobopt in the chapter COBOL System Interface (cob).

Examples

COBOPT="CANS85
set COBCPY=$COBDIR/srclib/:$HOME/mylib:"
export COBOPT

This enables ANSI 85 standard COBOL syntax and sets COBCPY to the specified list of paths.

COBOPT=temp/options

Specifies that cob options are contained in the file options in the directory temp.

COBPATH

Specifies the directory or directories that the runtime system is to search for dynamically loadable .int and .gnt files, or callable shared objects.

Syntax

COBPATH=pathname[:pathname]...
export COBPATH

Parameters

pathname A list of search directories, each item separated by a colon, that the runtime system is to search for a dynamically loadable program (.int, .gnt or callable shared object) file. When more than one pathname is specified, a null pathname represents the current working directory.

Example

COBPATH=u:/home/mydir/srclib:otherlib
export COBPATH

COBPRFDIR

Location of .ipf files created by programs compiled with the PROFILE compiler directive.

Values

A list of search directories, each item separated by a colon.

COBPRINTER

Specifies the name of a print spooler that is to receive, via its standard input stream (stdin), output from any DISPLAY UPON PRINTER statement.

Syntax

COBPRINTER=command-line
export COBPRINTER

Parameters

command-line A command line supported by your system and that can be executed by the system shell. Typically, it is simply the name of a print spooler or other executable, but if the shell is escaped when setting the value then any command-line arguments can be used.

Comments

Each DISPLAY UPON PRINTER statement executed by your COBOL program causes a new invocation of command-line. Each invocation receives the data referenced in the DISPLAY statement, and is followed by a system end-of-file condition.

Example

COBPRINTER="myspooler -a $TMPDIR/spoolfile"
export COBPRINTER

COBSES

Specifies the UNIX Session Recorder functions to perform.

Syntax

COBSES={option[filename]}...
export COBSES

Parameters

optioncan be one or more of the following:

-a Include keystrokes made to and screen output from the Animator
-f filename Play back recording in fast forward mode
-p filename Play back recording in filename at normal speed
-r filename Record keystrokes
-s filename Record screen output
-t terminal number Indicate terminal number for multi-user screen recordings

These flags are all case sensitive. Also, you cannot combine the -r flag with either -f or -p.

Note: You must unset COBSES when you have finished using the UNIX Session Recorder, or it will interfere with the running of your COBOL programs. To do this, set COBSES to spaces, then export this setting to the shell.

COBSSL

If using SSL connections specifies the location of the DemoCA directory. If not found, SSLDIR is inspected instead.

COBSW

Specifies the run-time system switch settings for the run-time system to observe when running an application.

Syntax

COBSW=[+/-}s...
export COBSW

Parameters

A list of the runtime switches to set or unset.

+ sets a switch.
- un-sets a switch.

Example

COBSW=+0+D
export COBSW

This enables runtime switch 0 and the ANSI COBOL debug switch.

COBTERMINFO

Specifies the directory or directories to be searched by the runtime system for a terminfo database of terminal information tailored to the needs of COBOL applications. This enables COBOL applications to use different terminfo settings to those used by non-COBOL applications, such as vi, when using the same terminal.

Syntax

COBTERMINFO=pathname[:pathname]...
export COBTERMINFO

Parameters

pathname A list of search directories, each item separated by a colon, that identify a terminfo database containing terminal settings tailored for COBOL applications. A null pathname represents the current working directory.

Comments

The COBOL system takes the value of the standard UNIX environment variable TERM as the name of the terminal in use. It uses this to search for the appropriate terminal information in a terminfo database. The runtime system first searches the databases identified in COBTERMINFO and then, if the terminal information is not found it searches the database identified in the standard UNIX environment variable TERMINFO.

If COBTERMINFO is not set, the runtime system acts as if it had been set to $COBDIR/terminfo.

Micro Focus recommend that the first directory listed in COBTERMINFO is $COBDIR/terminfo so that the terminfo database supplied with this COBOL system is found first. For commonly used terminals this terminfo contains settings that are fuller and more appropriate to COBOL than those normally available in the UNIX system terminfo database. When debugging using Animator, COBTERMINFO must be set to $COBDIR/terminfo.

COBTERMINFO can also be used to identify a terminfo database that is portable between UNIX systems. Such a database conforms to the standard UNIX database format but does not include any supplementary, UNIX implementation-dependent terminal information. Many UNIX system terminfo databases are not portable because they include such supplementary information. The COBOL system ignores any such nonportable details.

Example

COBTERMINFO=$COBDIR/terminfo:/home/mydir/terms
export COBTERMINFO

CODEWATCH_SRCPATH

The location of source files for the debugger to use if none are found in directories specified when invoking CodeWatch

Values

A list of search directories, each item separated by a colon.

CODEWATCH_STBPATH

The location of STB files for the debugger to use if none are found in directories specified when invoking CodeWatch.

Values

A list of search directories, each item separated by a colon.

COLUMNS

Specifies the column width of the terminal screen or window, overriding the specified terminal default.

Syntax

COLUMNS=n
export COLUMNS

Parameters

n The width of the terminal screen or window, in column positions.

Comments

The default, when COLUMNS is unset or null, is to use the cols value defined in the specified terminal's terminfo entry, or the current width of the terminal window if you are using an X terminal. The terminal type is specified using the standard UNIX environment variable, TERM.

On non-windowing environments, where the terminal screen area cannot be resized, the COLUMNS values does not need to be set. Terminals that can switch into a wide mode (usually from 80 through 132 columns) have a terminal name ending in "w" and these are automatically supported, without the need to set COLUMNS.

In windowing environments, where the size of windows can be changed, the initial size of the window is used in preference to the cols value in terminfo. When the window is resized, the new size is reread. If the new size is greater than the initial size then the extra columns might not be used.

If you want to use the full width of the window you might need to set COLUMNS to the current column width of the window on some platforms.

Using COLUMNS values that do not correspond to the actual width of the window produces unexpected results.

Example

COLUMNS=100
export COLUMNS

D

DB2DBDFT

The default database for the DB2 SQL precompiler to process SQL statements against.

Values

The location and name of the default database.

DBG_MVSPSKEL: The skeleton JCL for debugging.

E

ENTRYNAMEMAP

Specifies the locations of entry name map files to be used.

Syntax

ENTRYNAMEMAP={filename|directory}; ...
export ENTRYNAMEMAP

Parameters

filename An entry map file.

directory A directory containing an entry name map file. The name of the entry name map file must be mfentmap.dat.

Comments

You must set the entry_name_mapper tunable to enable entry point mapper support.

If ENTRYNAMEMAP is not set, the runtime system searches for an entry name map file called mfentmap.dat in each folder specified by the COBDIR environment variable.

If the runtime system finds more than one entry name map file and same entry point is defined differently in different files, precedence is given to the definition in the entry name map file that was found first. To change the order in which the runtime system finds entry name map files you need to change the order in which the files appear in the COBDIR or ENTRYNAMEMAP environment variable paths.

ES_ABORT_PLTPI_ERROR

Enables the user to set the error on which to abort PLTPI processing, bypassing the prompt.

Syntax

ES_ABORT_PLTPI_ERROR=xx

Values

Values for xx can be:

YN - Abort on PGMIDERR
NY - Abort on ABEND
YY - Abort on PGMIDERR or ABEND

Comments

By default, when an error occurs during PLTPI processing, mainframe CICS enterprise servers display a prompt that enables the user to cancel the startup or ignore the error. Set ES_ABORT_PLTPI_ERROR to bypass the prompt and automatically abort the initialization as dictated by the value provided.

ES_ACBLIB

Specifies the locations of the IMS ACB files.

Syntax

ES_ACBLIB={pathname
export ES_ACBLIB

Values

pathname The path location of the IMS ACB files.

Default

If this variable is not set the ACB files are assumed to be in the project directory.

ES_ALLOC_EXPAND

The default value is Y, which expands an environment variable when used to specify an allocation path. Set to N to override this behavior, which is to not expand the variable used in the path.

Syntax

ES_ALLOC_EXPAND=value
export ES_ALLOC_EXPAND

Values

Y Expands an environment variable used to specify an allocation path.

N Do not expand the variable used in the path.

Default

The default value is Y.

ES_ALLOC_OVERRIDE

The default value is Y, which expands an environment variable when used to specify an allocation path. Set to N to override this behavior, which is to not expand the variable used in the path.

Syntax

ES_ALLOC_OVERRIDE=rules-file
export ES_ALLOC_OVERRIDE

Values

rules-file The file path and name of the dataset rules file.

ES_CAS_API

Indicates whether casout or cassub has been executed by a call and not from the command line.

Syntax

ES_CAS_API=value
export ES_CAS_API

Values

ON The utility has been invoked by a call, and messages will not be sent to the console or command line.

Default

The utility will attempt to log messages.

ES_CERT_REG

Specifies the directory in which the cascertreg user certificate utility should store its registrations.

Syntax

ES_CERT_REG=pathname
export ES_CERT_REG

Values

pathname Pathname of the directory where registrations are stored.

Default

By default no directory is specified. In this case it must be specified on the cascertreg command.

ES_CESN_NO_OS390

Overrides the default behaviour CESN transaction response for invalid user credentials. Default behaviour reports "Your userid is invalid" or "Your password is invalid".

Syntax

ES_CESN_NO_OS390=value
export CESN_NO_OS390

Values

Setting this variable to any value causes CESN to produce an invalid credential message instead of a specific invalid user or invalid password message.

Default

Specific invalid user/password messages will be produced.

ES_CICS_SINGLE

Configures CICS so that a user can only log on once.

Syntax

ES_CICS_SINGLE=value
export ES_CICS_SINGLE

Values

Y|y A user can only log on once.

Default

Not set: A user can log on multiple times.

ES_CLASS_XPCT

Controls the CICS PCT resource class.

Syntax

ES_CLASS_XPCT=value
export ES_CLASS_XPCT

Values

Yes: ACICSPCT is the default PCT class
No: Security for PCTs will be bypassed
classname: Overrides the default PCT class ACICSPCT with Aclassname

Default

ACICSPCT is the default PCT class.

ES_CLASS_XCMD

Controls the CICS CMD resource class.

Syntax

ES_CLASS_XCMD=value
export ES_CLASS_XCMD

Values

Yes: CICS CMD is the default CMD class
No: Security for CMDs will be bypassed
classname: Overrides the default CMD class CICSCMD with Cclassname

Default

CICS CMD is the default CMD class.

ES_CLASS_XDCT

Controls the CICS DCT resource class.

Syntax

ES_CLASS_XDCT=value
export ES_CLASS_XDCT

Values

Yes: DCICSDCT is the default DCT class
No: Security for DCTs will be bypassed
classname: Overrides the default DCT class DCICSDCT with Dclassname

Default

DCICSDCT is the default DCT class.

ES_CLASS_XFCT

Controls the CICS FCT resource class.

Syntax

ES_CLASS_XFCT=value
export ES_CLASS_XFCT

Values

Yes: FCICSFCT is the default FCT class
No: Security for FCTs will be bypassed
classname: Overrides the default PCT class FCICSFCT with Fclassname

Default

FCICSFCT is the default FCT class.

ES_CLASS_XJCT

Controls the CICS JCT resource class.

Syntax

ES_CLASS_XJCT=value
export ES_CLASS_XJCT

Values

Yes: JCICSJCT is the default JCT class
No: Security for JCTs will be bypassed
classname: Overrides the default JCT class JCICSJCT with Jclassname

Default

JCICSJCT is the default JCT class.

ES_CLASS_XPPT

Controls the CICS PPT resource class.

Syntax

ES_CLASS_XPPT=value
export ES_CLASS_XPPT

Values

Yes: MCICSPPT is the default PPT class
No: Security for PPTs will be bypassed
classname: Overrides the default PPT class MCICSPPT with Mclassname

Default

MCICSPPT is the default PPT class.

ES_CLASS_XPSB

Controls the CICS PSB resource class.

Syntax

ES_CLASS_XPSB=value
export ES_CLASS_XPSB

Values

Yes: PCICSPSB is the default PSB class
No: Security for PSBs will be bypassed
classname: Overrides the default PSB class PCICSPSB with Pclassname

Default

PCICSPSB is the default PSB class.

ES_CLASS_XRES

Controls the CICS DOCTEMPLATE resource class.

Syntax

ES_CLASS_XRES=value
export ES_CLASS_XRES

Values

Yes: RCICSRES is the default RES class
No: Security for DOCTEMPLATEs will be bypassed
classname: Overrides the default RES class RCISRES with Rclassname

Default

RCISRES is the default RES class.

ES_CLASS_XTST

Controls the CICS TST resource class.

Syntax

ES_CLASS_XTST=value
export ES_CLASS_XTST

Values

Yes: SCITST is the default TST class
No: Security for TSTs will be bypassed
classname: Overrides the default TST class SCITST with Sclassname

Default

SCITST is the default RES class.

ES_CLASS_XTRAN

Controls the CICS TRAN resource class.

Syntax

ES_CLASS_XTRAN=value
export ES_CLASS_XTRAN

Values

Yes: TCICSTRN is the default TRAN class
No: Security for TRANs will be bypassed
classname: Overrides the default TRAN class TCICSTRN with Tclassname

Default

TCICSTRN is the default TRAN class.

ES_CLUSTER

Identifies a region as participating in an Enterprise Server Cluster. Mandatory for all regions in a cluster.

Syntax

ES_CLUSTER=ON
export ES_CLUSTER

Values

Default

If this is not set, the region will not participate in an Enterprise Server Cluster.

ES_CLUSTER_ISC_TRACE

Enables tracing on the Enterprise Server Cluster ISC listeners.

Syntax

ES_CLUSTER_ISC_TRACE=value
export ES_CLUSTER_ISC_TRACE

Values

Default

If this is not set, there is no tracing of Enterprise Server Cluster ISC listeners.

ES_CLUSTER_LISTENER_PORT_TO_USE

This variable enables you to use a specific port for a listener of the cluster.

Syntax

ES_CLUSTER_LISTENER_PORT_TO_USE=port
export ES_CLUSTER_LISTENER_PORT_TO_USE

Values

port A port number

Default

If this is not set, ES Cluster listeners will use ephemeral ports.

ES_CSKL_NO_MSG_CONSOLE

Stops CSKL writing messages to console.log

Syntax

ES_CSKL_NO_MSG_CONSOLE=value
export ES_CSKL_NO_MSG_CONSOLE

Values

Any. CSKL messages are not written to the console log.

Default

If this is not set, CSKL messages are written to the console log.

ES_CWS_WSBIND_COMP

Enables support of CICS applications that use COMP declarations.

Values

Y - Enables support for COMP declarations.
N - Does not enable support for COMP declarations.

Default

ES_DDBG_PORT_RANGE

A range of ports to use for dynamic debugging.

You specify a range of port numbers separated by a hyphen or a comma; the second port number must be greater than the first.

Syntax

ES_DDBG_PORT_RANGE=value
export ES_DDBG_PORT_RANGE

Values

low_port-high_port

Default

If this is not set, dynamic debugging will use random ports.

Example

ES_DDBG_PORT_RANGE=8001-8040

ES_DISABLE_DFLTUSR_SIGNON

Disables the default user ("mfuser") signon when invoking ES Monitor & Control (ESMAC).

Syntax

ES_DISABLE_DFLTUSR_SIGNON=value
export ES_DISABLE_DFLTUSR_SIGNON

Values

Y or y Having logged on to ES administration via your MFDS internal security account, you no longer receive the auto logon as "mfuser" when accessing ESMAC.

Default

If this is not set, mfuser will be used as the default user to sign in to ESMAC.

ES_DFS3650

The default transaction to execute or MOD file to be displayed after successfully signing on to IMS. You specify these by setting environment variables prior to the start of the region: ES_DFS3650 - set to MOD if a MOD file is to be sent, or TRX if a TRANSACTION is to be executed. If you set to MOD, ES_MOD3650 needs to be set to the name of the MOD you want to display. If you set to TRX, ES_TRX3650 needs to be set to the name of the transaction.

Syntax

ES_DFS3650=value
export ES_DFS3650

Values

MOD - ES_MOD3650 needs to be set to the name of the MOD you want to display
TRX - ES_TRX3650 needs to be set to the name of the transaction

Default

No default transaction or MOD.

ES_ECI_MAX_RESP

Specifies the maximum expected response size (in bytes) to use when using Micro Focus ECI support to invoke CICS programs. You need to use this environment variable when the amount of data returned from the CICS programs is approximately more than twice the size of the input data, which is sometimes the case when using channels and containers where the back-end program creates or enlarges containers.

Syntax

ES_ECI_MAX_RESP=value
export ES_ECI_MAX_RESP

Values

Maximum value is 16777215.

Default

If this is not set, the maximum expected response size is calculated dynamically by multiplying the size of the TIOA by 2.

ES_ESM_CMDSEC

Indicates whether CICS processing honors the CMDSEC option specified on a transaction's PLT definition.

Syntax

ES_ESM_CMDSEC=value
export ES_ESM_CMDSEC

Values

YES - CICS overrides the CMDSEC option, and always calls its command security checking routine to issue the appropriate call to the SAF interface

Default

CICS honors the CMDSEC option defined in a transaction's resource definition. CICS calls its command security checking routine only when CMDSEC(YES) is specified in a transaction resource definition.

ES_ESM_IDPW_CASE

Forces the case of user ID and password for single attempt ESM authentication. You use the environment variable with a format ES_ESM_IDPW_CASE=xy, where "x" is the folding option for user ID, and "y" the option for password.

Syntax

ES_ESM_IDPW_CASE=xy
export ES_ESM_IDPW_CASE

Values

Values for both x and y are:

U - Always upper case.
L - Always lower case.
M - Mixed case and case sensitive

Default

Legacy behavior.

Comments

When this environment variable is set, Enterprise Server will only make one attempt to identify a user presenting the user ID and password as is (M), folded to uppercase (U) or folded to lower case (L). If this environment variable is not set, the legacy Enterprise Server behavior will be used.

For the legacy behavior for CICS, the User ID and the password are used as supplied possibly filtered by the uppercase translation configuration of the sign-on transaction.

For ESMAC and IMS, the legacy behavior is that, first, the user ID and password are used as supplied. If the authentication fails, the user ID is folded to uppercase and used again. If this fails as well, both the user ID and the password are folded to uppercase and then used.

Example

ES_ESM_IDPW_CASE=UM - a single authentication is tried with the user ID folded to uppercase, and the password used as-is.

ES_ESM_PLTPISEC

The level of security checking for PLTPI processing.

Syntax

ES_ESM_PLTPISEC=value
export ES_ESM_PLTPISEC

Values

NONE - You do not want any security checking on PLT initialization programs.
CMDSEC - You want CICS to perform command security checking only.
RESSEC - You want CICS to perform resource security checking only.
ALL - You want CICS to perform both command and resource security checking.

Default

NONE

ES_ESM_PLTPIUSR

The user id under which PLT programs run during CICS initialization.

Syntax

ES_ESM_PLTPIUSR=userid
export ES_ESM_PLTPIUSR

Values

userid - The userid that CICS is to use for security checking for PLT programs that run during CICS initialization.

ES_ESM_RCF

Determines how RACF is used for command authorization

Syntax

ES_ESM_RCF=value
export ES_ESM_RCF

Values:

A Includes options T, C, and S.
C Specifies that RACF is to be used for ETO terminal command authorization.
N Specifies that no sign-on, transaction, or command authorization is to be performed by RACF.
S Specifies that RACF is to be used for static and ETO terminal command authorization. Includes option C.
T Specifies that RACF is to be used for sign-on and transaction authorization.
Y Includes options T and C.

Default

ES_ESM_RESSEC

Indicates whether CICS processing honors the RLS security setting specified on a transaction definition (PCT).

Syntax

ES_ESM_RESSEC=value
export ES_ESM_RESSEC

Values:

ALWAYS - CICS processing always performs resource level security checking irrespective of the RLS security setting on the transaction definition.

Default

If this is not set, the RLS security setting of a transaction will be honored. That is, resource level security checking is performed only when the RLS security checkbox is marked in the PCT definition.

ES_ESM_SECPRFX

Indicates whether CICS processing prefixes the resource names when making security queries.

Syntax

ES_ESM_SECPRFX=value
export ES_ESM_SECPRFX

Values

NO - No prefixes are used.
YES - Resource names are prefixed with the CICS region user ID.
prefix - A string to be used as the prefix for resource names. It can be 1 to 8 upper case alphanumeric characters and it must start with an alphabetic character.

Default

NO

ES_ESM_XUSER

Indicates whether CICS processing performs surrogate user checks.

Syntax

ES_ESM_XUSER=value
export ES_ESM_XUSER

Values

NO - No surrogate user checking is performed.
YES - Perform surrogate user checking wherever such checks are permitted.

Default

YES

ES_ESMAC_DISP_MAX_OVERRIDE

Limits the number of lines shown when viewing an individual catalog entry in the ESMAC catalog view or when viewing a SYSOUT file from the job list view.

Syntax

ES_ESMAC_DISP_MAX_OVERRIDE=value
export ES_ESMAC_DISP_MAX_OVERRIDE

Value

An integer number denoting how many lines to display. The maximum number is 99999.

Default

10000

ES_EUSA_SIZE

Sets the size of the extended user storage area, allowing large memory allocations to be set using the GETMAIN SHARED command. Set this variable to a numeric value representing the number of MB.

Syntax

ES_EUSA_SIZE=number
export ES_EUSA_SIZE

Values

Number of MB for the extended user storage area.

Default

16 MB

ES_GLM

If this variable is set, it identifies the region as an Enterprise Server Cluster Global Lock Manager (GLM).

Syntax

ES_GLM=value
export ES_GLM

Values

Any value sets the variable.

Default

If this variable is not set, the region is not a Global Lock Manager (GLM).

ES_GLM_TIMEOUT

The duration in which a submit request to an Enterprise Server Cluster Global Lock Manager (GLM) can be retried before disabling the connection permanently.

Values

n seconds.

This variable only applies to the region within an Enterprise Server Cluster designated as the GLM.

Syntax

ES_GLM_TIMEOUT=seconds
export ES_GLM_TIMEOUT

Values

The number of seconds within which a request can be retried..

Default

120 seconds.

Comments

Only applies to the region within an Enterprise Server Cluster designated as the GLM.

ES_HOSTNAME_TO_USE

In an Enterprise Server Cluster, if a machine uses more than one network card, you may need to set this variable to indicate which hostname MFCS should use.

Syntax

ES_HOSTNAME_TO_USE=hostname
export ES_HOSTNAME_TO_USE

Values

The relevant hostname.

ES_IMS_BASIC_CHKP_OPT

When set to 1, enables a basic checkpoint call to process as if a SYNC call had been issued. The default is 0 (zero).

ES_IMS_BYPASS_OTMA_DEST_RES

By default, a CHNG call issued from an OTMA- or IMS Connect-submitted transaction assumes that the destination is the OTMA client. In some circumstances, the previous behavior of assuming a non-OTMA client is desirable. To use the previous behavior, set this environment variable to Y.

Values

Y
N. This is the default.

Example

ES_IMS_BYPASS_OTMA_DEST_RES=Y

ES_IMS_CONFIG

The IMS TM parameters.

ES_IMS_DB_COMMIT_FLUSH

When set to 0 (zero), forces the flushing of database buffers to disk on CLOSE only (default). When set to 1, forces the flushing of database buffers to disk on COMMIT only.

ES_IMS_DB_TLOG_WRITETHRU

When set to 0 (zero), forces the flushing of TLOG buffers to disk on COMMIT only (default). When set to 1, forces the flushing of TLOG buffers to disk on all database I/O.

ES_IMS_DEADLOCK_WAIT

Time in milliseconds to wait before checking for a deadlock. The default is 1000 (1 second).

ES_IMS_DIAGNOSE

Marks IMS TM as diagnose mode only for IMSMSGQ.

Values

Y The Transaction Manager (TM) works in diagnostic mode only, and no activity key points are written to the message queue. Use this feature only when advised to do so by Micro Focus.

ES_IMS_DOSVS_PCB

Emulates DOS/VSE PCB address alignment for EXEC DLI programs.

ES_IMS_DUMP_ON_DEADLOCK

Creates a system dump when a deadlock is detected.

ES_IMS_DUMP_ON_TIMEOUT

Creates a system dump when a lock timeout occurs.

ES_IMS_EXITPATH

The location of compiled code that contains segment and/or field exits.

ES_IMS_FORCE_SIGNON

Enables a user to force a sign-on to IMS on the current terminal and sign off from other terminals.

ES_IMS_GOTO_CICS_ON_SIGNOFF

Returns to CICS upon logging off or timing out, rather than returning to the IMS sign-on screen, which is the default behavior.

ES_IMS_IBMPLATFORM

Sets the emulation for the IMS run-time. Valid values are: M (for MVS) or D (for DOSVS). The default value is M.

Note: This variable is rarely required to be changed from its default, even for the majority of DOSVS users.

ES_IMS_IMSID

Allows the user to specify the IMS System ID returned to the AIBTDLI INQY ENVIRON call.

ES_IMS_INQY_OTMA

Returns TPIPE, MBR, SYNC, and MSYNC to an INQY call.

ES_IMS_INQY_UNKNOWN

Value returned to an INQY call.

ES_IMS_LOCALDLI

Deprecated. See IMS Database Locking. When set to 1, directs batch program execution to process all IMS DB calls entirely in the JES initiator providing significant performance improvement. All IMS DB control processes accessed from the batch program must be stopped before execution because they become exclusively owned by JES until the program completes.

ES_IMS_IRLM

Enables Internal Lock Resource Manager (IRLM) locking. IRLM locking more closely parallels mainframe IMS database DB locking behavior, reducing data constraint and potential for deadlock.

ES_IMS_LOCK_TIMEOUT

Allows the user to specify the IMS System ID returned to the AIBTDLI INQY ENVIRON call.

ES_IMS_LOCK_RETRY_DELAY

The IMS DB lock retry delay in milliseconds.

ES_IMS_LU_LTERM

Determines the value of the LTERM literal returned by the MFS system. Valid values are: Y to return the LU name; N to return the user ID.

ES_IMS_MESGQ

Sets the configuration for the IMS TM message queue. The ES_IMS_MESGQ environment variable is generated and set automatically by Enterprise Server, and is reserved.

Restriction: Manually set this variable only when advised to do so by Micro Focus SupportLine.

ES_IMS_MESGQ=[ds-file-name];max-blocks;buffer-count;start-control;[cushion-size]

ds-file-name

An alternative data store file to the default, which is IMSMESGQ.dat.

max-blocks

Data store size limit represented as the number of 64K blocks. Default is 4.

buffer-count

The number of 64K buffers to allocate. Default is 2.

start-control

A flag that sets the start behavior as follows:

Y	Cold start the resource definitions. Default.
S	Cold start the statistics and resource state information.
Q	Cold start the data store (system cold start).

cushion-size

The size of the cushion to be reserved for graceful lack-of-space behavior, represented as a number from 0 to 255. The specified number represents 32 times the actual percentage of max-blocks reserved for emergency use. The default is 4 (a raw value of 128).

ES_IMS_PATH

The location of compiled COBOL applications.

ES_IMS_PLI_INDIRECT_PCBADDR

Determines whether the PL/I program converts the PCB address list from a direct to an indirect addressing technique. Set the variable to one of the following:

D: If the main program is a PL/I program, PCB addresses are converted from a direct to an indirect addressing technique.
Y: Always converts address as long as the PSB language is PL/I.
N: Never converts addresses.

The default is D (which stands for dynamic).

ES_IMS_RELEASE

Allows the user to specify the IMS Release returned to the AIBTDLI INQY ENVIRON call.

ES_IMS_REGION

Allows the user to specify the IMS Region returned to the AIBTDLI INQY ENVIRON call.

ES_IMS_ROLLBACK

Enables automatic Backward Recovery; enabled by default.

ES_IMS_ROLLFORWARD

Enables or disables Forward Recovery logging. Valid values are: Y to enable; N to disable. The default is N.

ES_IMS_SPARSE_EXIT_LANG

Indicates the language of the IMS DB secondary index sparse routines. Set the variable to one of the following values:

C (for COBOL)
A (for Assembler)

By default, this variable is not set (sparse exits are disabled).

ES_IMS_SUPPORT

Enables IMS support.

ES_IMS_TLOG_COMPRESS

When set to 0 (zero), disables compression of the Backward Recovery TLOG file. When not compressed, the file contains only the information required to recover databases. The default is enabled.

Note: When enabled, Enterprise Server reclaims space in the file when information becomes obsolete.

ES_IMS_TLOG_FLUSH

When set to 1, forces the frequent flushing of TLOG and database buffers to disk.

Warning: Depending upon the number of database updates, the frequency of commits, and other computer activity, use of ES_IMS_TLOG_FLUSH could result in significant performance degradation.

Note: This environment variable is deprecated. Use ES_IMS_DB_TLOG_WRITETHRU to flush TLOG buffers and ES_IMS_DB_COMMIT_FLUSH to flush database buffers.

ES_IMS_TLOG_MAXSIZE

Maximum size of the IMS DB transaction logging file in bytes. The default is 4GB or h"FFF00000".

ES_IMS_TLOG_PATH

The location of IMS DB transaction logging files. The default is the Enterprise Server system directory.

ES_IMS_TLOG_THRESHOLD

Threshold size of the IMS DB transaction logging file. When reached, the current TLOG file is closed and a new TLOG file created for subsequent transactions. The default is 2GB or h"7FFFFFFF".

ES_IMSCFG

The location of the IMS configuration files IMSCONFG.DAT. This is reserved for future use.

ES_IMSDAT

The location of IMS DB data files.

ES_IMSLIB

The location of DBDGEN2.DAT, DBDGEN2F.DAT and PSBGEN3.DAT files.

ES_INQFILE_RETURN

Modifies EXEC CICS INQUIRE FILE behavior for catalogued files.

Syntax

ES_INQFILE_RETURN=value
export ES_INQFILE_RETURN

Parameters

DSN - the DSN is returned. For an alternate file the BASEDSNAME will be the DSNAME of the BASE file.
PCN - the PC name of the file is returned.

Default

PCN

ES_JESYSMSG_OUTPUT

The status of the system messages spool files (JESYSMSG) is set to Output, rather than Out Hold.

Syntax

ES_JESYSMSG_OUTPUT==Y|N}
export ES_JESYSMSG_OUTPUT

Values

Y All job messages will have the status as Output, but will only actually print (either physically or logically) if the MSGCLASS of the job matches one of the sysout classes defined to an active printer.
N Messages are set to Out Hold

Default

The default is N.

ES_JES_BYTES

Maximum number of bytes to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)

ES_JES_CARDS

Maximum number of cards to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)

ES_JES_DISABLE_RESTART_FLUSH

Indicates whether a region's jobs are moved from the Active queue to the Complete queue when a region is restarted

ES_JES_FREE_SSTM_SYSOUT

When set to Y, decreases the amount of memory used when processing CICS spool datasets in an SSTM enterprise server.

ES_JES_LEVEL

Sets the default JCL type on the JES Control page.

Syntax

ES_JES_LEVEL=type
export ES_JES_LEVEL

Values

type is the default JCL type, one of:

VSE
JES2
JES3

Default

JES2

ES_JES_LINES

Maximum number of lines to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)

ES_JES_OUTLIM

Maximum number of lines to output to a particular dataset before calling the user exit, processing any global limits, and then cancelling the job

ES_JES_PAGES

Maximum number of pages to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)

ES_JES_PARM_INIT_LOW

When set to Y, the parameter string passed to a program executed by JCL is initialized to low-values. The default is N, which is to initialize it to spaces.

ES_JES_RESTART

Enables JCL restart processing.

Syntax

ES_JES_RESTART=value
export ES_JES_RESTART

Values

Y|y Enables restart processing.

Default

By default JCL restart processing is not enabled.

ES_JES_SPOOL_ORDER

The order in which the spool list is displayed when you first open ESMAC.

Syntax

ES_JES_SPOOL_ORDER=value
export ES_JES_SPOOL_ORDER

Values

1 - Displays the list in descending order by JOBID. Any other value displays it in ascending order.

Default

By default the list is displayed in ascending order by JOBID.

ES_LE370_SUPPORT

Enables support for Language Environment (LE) in CICS applications

Syntax

ES_LE370_SUPPORT=value
export ES_LE370_SUPPORT

Values

Y|y Enables LE support.

Default

By default LE support is not enabled.

ES_LEGACY_ECI

Indicates that Enterprise Server must use Micro Focus ECI instead of IBM CTG.

Syntax

ES_LEGACY_ECI=value
export ES_LEGACY_ECI

Values

Y|y Micro Focus ECI is used.

Default

By default IBM CTG is used.

ES_MAX_CATALOG_LINES

Restricts the number of entries displayed in ESMAC catalog view.

Syntax

ES_MAX_CATALOG_LINES=number
export ES_MAX_CATALOG_LINES

Values

number The number of lines to display. The maximum is 99999.

Default

The default is 5000.

ES_MEM_STRATEGY

Selects the types of memory processes supported.

Note: Note that memory strategy can also be set via the memory_strategy runtime tunable.

ES_MFASM_SUPPORT

Enables Assembler support when running CICS server regions.

Syntax

ES_MFASM_SUPPORT=value
export ES_MFASM_SUPPORT

Values

Y|y
Assembler supported for CICS server regions.
N|n
No Assembler supported for CICS server regions.

Default

By default Assembler support is not enabled.

ES_MFSLIB

The location of the control blocks generated by the MFS generation program.

Syntax

ES_MFSLIB=pathname
export ES_MFSLIB

Values

pathname The path to the MFS directory.

Default

product_install_dir/etc/ims

ES_MOD3650

The default MOD file to be displayed after a successful sign-on to IMS. See ES_DFS3650.

Syntax

ES_MOD3650=filename
export ES_MOD3650

Values

filename - The name of the MOD file.

ES_MQ_1PC

Indicates whether the IBM WebSphere MQ switch module ESMQXA should operate in one-phase commit mode. Set this environment variable only when advised to do so by Micro Focus.

Syntax

ES_MQ_1PC=value
export ES_MQ_1PC

Values

Y|y|T - ESMQXA operates in one-phase commit mode.

Default

By default ESMQXA does not operate in one-phase commit mode.

ES_MQ_LIB

The full name including the path of the IBM WebSphere MQ client or server library. This should only be required if MQ was NOT installed in the default location.

Syntax

ES_MQ_LIB= fully_qualified_library
export ES_MQ_LIB

Values

fully_qualified_library - A fully-qualified library name.

Default

By default ES will try to locate libraries in the default location for the platform.

Important: In AIX environments the library is an object inside a shared object. For example

ES_MQ_LIB="/usr/mqm/lib64/libmqmxa64.a(libmqm64.o)"

ES_MQ_LIB_T

The full name including the path of the IBM WebSphere MQ client or server library, for threaded environments. This should only be required if MQ was NOT installed in the default location.

Syntax

ES_MQ_LIB_T= fully_qualified_library
export ES_MQ_LIB_T

Values

fully_qualified_library - A fully-qualified threaded library name.

Default

By default ES will try to locate threaded libraries in the default location for the platform.

ES_MQ_LIB_XA

The full name including the path of the IBM WebSphere MQ XA library. This should only be required if MQ was NOT installed in the default location.

Syntax

ES_MQ_LIB_XA= fully_qualified_library
export ES_MQ_LIB_XA

Values

fully_qualified_library - A fully-qualified library name.

Default

By default ES will try to locate libraries in the default location for the platform.

Important: In AIX environments the library is an object inside a shared object. For example

ES_MQ_LIB="/usr/mqm/lib64/libmqmxa64.a(libmqm64.o)"

ES_MQ_LIB_XA_T

The full name including the path of the IBM WebSphere MQ XA library, for threaded environments. This should only be required if MQ was NOT installed in the default location.

Syntax

ES_MQ_LIB_XA_T= fully_qualified_library
export ES_MQ_LIB_XA_T

Values

fully_qualified_library - A fully-qualified threaded library name.

Default

By default ES will try to locate threaded libraries in the default location for the platform.

ES_MQ_LISTENER (deprecated)

Defines one or more WebSphere MQ listeners.

Note: ES_MQ_LISTENER is deprecated, and provided for backward compatibility only. We recommend that you use MFDS configuration instead.

Syntax

ES_MQ_LISTENER={QueueManagerName,QueueName,ListenerName}
[,QueueManagerName,QueueName,ListenerName}...
export ES_MQ_LISTENER

Values

QueueManagerName,QueueName,ListenerName - the characteristics of the listener being defined.

Default

By default, no WebSphere MQ listeners are defined.

ES_MQ_XA

The type of XA structure to use for the two-phase commit XA switch module.

Syntax

ES_MQ_XA=value
export ES_MQ_XA

Values

D: use a dynamic XA structure
S: use a static XA structure

Default

By default, a dynamic XA structure is used.

ES_OLD_DYN_PDS

Determines the resulting behavior of dynamic PDS members when specified in a JCL DD statement.

Values

Y Enables previous default behavior of cataloging and creating the physical files for dynamic PDS when referenced in a JCL DD statement.

N Physical files for dynamic PDS members are only created and cataloged when created using the JCL utility or by a user program.

Default

The default value is N.

ES_OLD_SEC_TSTD

Prevents security being enforced for TS or TD queues that are not declared in the security repository.

Syntax

ES_OLD_SEC_TSTD=value
export ES_OLD_SEC_TSTD

Values

Any value.

Default

By default security is enforced for TS or TD queues that are not declared in the security repository.

ES_OTMA_TIMEOUT

The time in seconds that an OTMA client should wait for an answer. The default value is 120.

Syntax

ES_OTMA_TIMEOUT=seconds
export ES_OTMA_TIMEOUT

Values

seconds - The number of seconds to wait. The maximum is 43199.

Default

120 seconds.

ES_PL1_MFFH

Enables Micro Focus File Handler to perform all Open PL/I I/O operations. The default value is "Y". If it is set to "N", then all I/O will be routed to old Liant file handlers.

Syntax

ES_PL1_MFFH=Y|N
export ES_PL1_MFFH

Values

Y Micro Focus File Handler is used to perform all Open PL/I I/O operations.

N All I/O is routed to old Liant file handlers.

Default

The default value is Y.

ES_PL1_MFFH_JCL

Enables you to run Open PL/I programs that access JCL data definitions.

Syntax

ES_PL1_MFFH_JCL=Y|N
export ES_PL1_MFFH_JCL

Values

Y You can run Open PL/I programs that access JCL data definitions.

N Open PL/I programs cannot access JCL data definitions.

Default

The default value is N.

ES_PLI_SUPPORT

Tells the CICS Emulation that it needs to load its subsystem support for PL/I user programs.

Syntax

ES_PLI_SUPPORT=value
export ES_PLI_SUPPORT

Values

Y|y - PL/I support is enabled.

Default

PL/I support is not enabled.

ES_PROG_PATH

Set ES_PROG_PATH=Y to display the program's load path in the JESYSMSG and SYSLOG datasets.

Note: This is only applicable for native enterprise server regions.

ES_RLS_FILE_SUPPORT

If a record is locked because a program is doing a read for update, and the application needs to ensure that no other program can access that record, you can set this environment variable to avoid returning a dirty record until the program holding the lock has completed. The timeout in fileshare also needs to be set to 0 using /t 0 in the fileshare configuration file.

Syntax

ES_RLS_FILE_SUPPORT=value
export ES_RLS_FILE_SUPPORT

Values

Y|y - Stops dirty records being returned when a record is locked by another process.

Default

RLS file support is off.

ES_SAM_ESDS: Under VSE, when this is set to Y, opening an OUTPUT of a reusable ESDS file resets the file when the DISP is not specified in the DLBL statement.

ES_SEP_DORMANT_TIME

Allows override of Transient SEP dormant time. Rather than automatically terminating transient SEPs on completion of a stateful request, the server manager allows a period of inactivity before scheduling their termination. This allows new requests to re-use the SEP rather than starting a new instance. This environment variable allows the period of inactivity to be controlled.

Syntax

ES_SEP_DORMANT_TIME=seconds
export ES_SEP_DORMANT_TIME

Values

seconds Number of seconds' inactivity.

Default

Transient SEPs are terminated after 2 seconds of inactivity.

ES_SERVER

The default server name (used if no -r switch is specified on casstart or casstop).

Syntax

ES_SERVER=name
export ES_SERVER

Values

name The server name.

Default

ESDEMO/ESDEMO64

ES_SSTM_CICS

Location of the JCL used to initialize the SSTM CICS environment

ES_SSTM_IMS

Location of the JCL used to initialize the SSTM IMS environment.

ES_SSTM_JOB_FLUSH_ACTIVE

By default, this is set to N. When set to Y, it causes a CICS SSTM job to be removed from the ACTIVE queue when the region shuts down.

ES_SURROGATE_JOB_USER

Associates a user ID with a job when submitting the job for processing through the internal reader from CICS.

Syntax

ES_SURROGATE_JOB_USER=value
export ES_SURROGATE_JOB_USER

Values

Any value - The user ID that started the ES region is used in the job submission.

Default

By default, the CICS default user CICSUSER, or as specified by ES_USR_DFLT_CICS, is used in the job submission.

ES_SYSOUT_HOLD: The status of the SYSOUT files are set to Out Hold.

ES_TMC_AGGREGATE

Controls the performance environment for IMS TM data stores.

Syntax

ES_TMC_AGGREGATE={[,N|,D]|nnn,Y}
export ES_TMC_AGGREGATE

Values

,N

Sets the default behavior, which is to unilaterally flush operating system buffers to your physical disk at each key transactional point. While this does not change the method used by default at startup, it does enable dynamic modification via ESMAC. Once set, you can then test the effect of various non-default settings by altering them dynamically.

,D

Disables the transactional flushing of operating system buffers to disk. This option can significantly enhance message queue performance; however it is at the expense of the transactional integrity of the message queue in the event of a system failure.

Note: To avoid unpredictable results when using this setting, we highly recommend that you also set the static options as follows on the Administration Server > Properties > MSS > IMS > TM > General tab:

Set Cold start to Everything (queue)
Check Persist

See Server Instance Properties: MSS IMS TM General for details.

nnn,Y

Enables the aggregated transactional flushing of operating system buffers to disk where nnn represents an interval of time, in milliseconds, during which additional buffers are allowed to accumulate before flushing. Valid values are 0 through 255.

Once a thread reaches a key transactional point and requests a flush, TM waits the specified interval to accumulate subsequent threads that also request a flush. At the end of the interval, one flush is performed for all accumulated requests thus potentially improving performance by reducing the number of flush commands issued to the operating system.

Note:

Threads requesting a flush wait until the flush is confirmed.
Generally, when the message queue resides on a higher performance I/O subsystem such as one using SSDs, a smaller value, e.g. 1 or 2, produces the best results. A value of 10 or higher seldom improves performance.

Default

ES_TN3270_FORCE_ALT

Enables you to use a screen size other than the default when using a TN3270 terminal emulator.

Syntax

ES_TN2370_FORCE_ALT=value
export ES_TN2370_FORCE_ALT

Values

Any value

Default

The default screen size is used.

ES_TN3270_MODEL_LOG

Writes the TN3270 emulator's model name to a temporary storage queue named TN32MODL that can be viewed using the CEBR transaction.

Syntax

ES_TN2370_MODEL_LOG=value
export ES_TN2370_MODEL_LOG

Values

Y|y - Model names are written to TSQ TN32MODL.

Default

Model names are not logged.

ES_TEST_TRANCLASS

Activates transaction class support.

Syntax

ES_TEST_TRANCLASS={Y|N}

Values

Y	Activate transaction class support
N	Do not activate transaction class support

Default

N, no transaction class support.

ES_TRANCLASS_CWI

For CICS Web Services, enables the prioritizing and limiting of Web requests in a TRANCLASS-enabled region.

Syntax

ES_TRANCLASS_CWI={TCPIPSERVICE|URIMAP}

Values

TCPIPSERVICE	Prioritize and limit TCPIPSERVICE transactions
URIMAP	Prioritize and limit URIMAP transactions

Default

TCPIPSERVICE

ES_TRX3650

The default transaction to run after a successful sign-on to IMS. See ES_DFS3650.

Syntax

ES_TRX3650=transaction
export ES_TRX3650

Values

transaction The default transaction to run.

ES_USR_DFLT_CICS

Allows you to override the default user when no user is logged on for CICS authentication.

Syntax

ES_USR_DFLT_CICS=user
export ES_USR_DFLT_CICS

Values

user - the default user name.

Default

CICSUSER

ES_USR_DFLT_ESMAC

Allows you to override the default user when no user is logged on for ESMAC authentication.

Syntax

ES_USR_DFLT_ESMAC=user
export ES_USR_DFLT_ESMAC

Values

user - the default user name.

Default

mfuser

ES_ESM_DISABLE_DFLTUSER_ESMAC

Allows you to disable the default ESMAC user in order to increase the security of your server. Disables the DEFAULT button on the logon screen and forces users to always enter a valid userid and password.

Syntax

ES_ESM_DISABLE_DFLTUSER_ESMAC=value
export ES_ESM_DISABLE_DFLTUSER_ESMAC

Values

Y|y - Default ESMAC user is disabled.

Default

Default ESMAC user is not disabled.

ES_USR_DFLT_JES

Allows you to override the default user when no user is logged on for JES authentication.

Syntax

ES_USR_DFLT_JES=user
export ES_USR_DFLT_JES

Values

user The deafult user name.

Default

JESUSER

ES_USR_DFLT_IMS

Allows you to override the default user when no user is logged on for IMS authentication.

Syntax

ES_USR_DFLT_IMS=user
export ES_USR_DFLT_IMS

Values

user - The user name to override the default.

Default

IMSUSER

ES_XA_????_NB_RETRIES

Operates in conjunction with ES_XA_CONNECT. Sets the number of connection re-tries when attempting to connect to a resource.

Syntax

ES_XA_????_NB_RETRIES=nnnn
export ES_XA_????_NB_RETRIES

Values

???? is the XA ID defined in MFDS.
nnnn is the number of subsequent XA call failures allowed before the SEP is recycled and the switch disabled.

Default

5 retries (ES_XA_RECONNECT must have been set).

ES_XA_LOG_SUPPRESS

Suppresses XA logging and the recovery of in-doubt XA transactions.

Syntax

ES_XA_LOG_SUPPRESS=value
export ES_XA_LOG_SUPPRESS

Values

Y|y - XA logging is suppressed.

Default

By default no value is specified and XA logging is not suppressed.

ES_XA_RECONNECT

If this environment variable is set, when an error occurs on a call to XA, the server recycles the SEP and attempts to reconnect to the Resource Manager. The ES_XA_????_NB_RETRIES variable specifies the number of XA call failures allowed before the SEP is recycled and the switch disabled.

Syntax

ES_XA_RECONNECT=user
export ES_XA_RECONNECT

Values

Any value.

Default

No value is set and the XA reconnect feature is not enabled.

ES_EZASOKET_SUPPORT (deprecated)

Switches on EZASOKET support.

Note: ES_EZASOKET_SUPPORT is deprecated, and provided for backward compatibility only. We recommend that you configure EZASOKET by using Enterprise Server Administration instead.

Syntax

ES_EZASOKET_SUPPORT=value
export ES_EZASOKET_SUPPORT

Values

Y|y - EZASOKET support is enabled.

Default

By default no value is set and EZASOKET support is not enabled.

EXTFH

Specifies a configuration file for the Callable File Handler.

Syntax

EXTFH=filename.cfg
export EXTFH

Parameters

filename.cfg The name of the configuration file.

Example

EXTFH=/home/mydir/myconfig.cfg
export EXTFH

F

FHREDIR

Specifies a configuration file to be used by the Fileshare Client.

Syntax

FHREDIR=filename.cfg
export FHREDIR

Parameters

filename.cfg The name of the configuration file.

Example

FHREDIR=/home/mydir/myconfig.cfg
export FHREDIR

FS

Specifies a configuration file to be used by the Fileshare Server.

Syntax

FS=filename.cfg
export FS

Parameters

filename.cfg The name of the configuration file.

Example

FS=myconfig.cfg
export FS

FSCOMMS

Specifies that the Fileshare system is to run in single user mode.

Syntax

FSCOMMS="\$local"
export FSCOMMS

Parameters

"\$local" Run the Fileshare System in single user mode.

H

HCOBND (deprecated)

Specifies a directory to be used for bind files generated by the DB2 External Compiler Module (ECM).

Note: HCOBND is deprecated, and provided for backward compatibility only. We recommend that you use either the BIND or the BINDDIR compiler directive option instead.

Syntax

Parameters

pathname The directory that the DB2 ECM is to use to store bind files.

Example

SET HCOBND=/mydir/binds
export HCOBND

Comments

The DB2 ECM uses the specified directory until the variable is unset or reset to a different directory. The DB2 Compiler directive option BIND overrides this environment variable.

I

ICONN1: Controls the client TCP connection status of an IMS Connect emulator.
IMSCPY: The location of copybook files for DBDGEN, PSBGEN and MFSGEN utilities .

ISPPROF: The location of ISPF dialog profiles.

J

JAVA_HOME: Specifies the location of the JDK.

L

LANG

Specifies the locale.

Syntax

LANG=language[_territory[.codepage]]
export LANG

Parameters

language The language in which your program is to run.
_ (underscore) The delimiter for language and territory, if territory is specified.
territory The country in which your program is to run.
. (period) The delimiter for territory and codepage, if codepage is specified.
codepage The character set to use for your program.

Example

LANG=fr_FR
export LANG

LD_LIBRARY_PATH

Specifies the directory or directories for the UNIX system, cob command, and the run-time system to search for shared libraries and callable shared objects. If you have installed the product to a directory other than the default one, you must set this variable to include $COBDIR/lib on all platforms except AIX (which uses LIBPATH). It should also include any directories that contain callable shared objects used by your application. If you have installed the product in the default directory (/opt/microfocus/EnterpriseDeveloper), you do not need to set this variable.

Syntax

LD_LIBRARY_PATH=pathname[:pathname]...
export LD_LIBRARY_PATH

Parameters

pathname A path or a list of paths, each separated by a colon (:).

Comments

The list of directories must include $COBDIR/lib. The COBDIR environment variable is described earlier.

This environment variable is a system environment variable; see your UNIX documentation for more information.

Example

LD_LIBRARY_PATH=$COBDIR/lib:/home/mydir/myapp:$LD_LIBRARY_PATH
export LD_LIBRARY_PATH

LIB: The location of the DB2 LIB directory

LIBLIST: Reserved for use by Micro Focus. Use only if directed by Micro Focus Technical Support.

LIBPATH

Specifies the directory or directories for the UNIX system, Cob and the runtime system to search for shared libraries and callable shared objects. It is only available on AIX-based systems. If you have installed the product to a directory other than the default one, you must set this variable to include $COBDIR/lib. It should also include any directories that contain callable shared objects used by your application. If you have installed the product in the default directory (/opt/microfocus/EnterpriseDeveloper), you do not need to set this variable.

Syntax

LIBPATH=pathname[:pathname]...
export LIBPATH

Parameters

pathname A directory to search for shared libraries.

Example

LIBPATH=$COBDIR/lib:/lib:/usr/lib

LINES

Specifies the depth of the terminal screen or window, overriding the specified terminal default.

Syntax

LINES=n
export LINES

Parameters

n The depth of the terminal screen or window, in lines.

Comments

The default, when LINES is unset or null, is to use the lines value as defined in the specified terminal's terminfo entry, or the current depth of the terminal window if you are using X windows. The terminal type is specified via the standard UNIX environment variable, TERM.

On non-windowing environments, where the terminal screen area cannot be resized, the LINES values does not need to be set.

In windowing environments, where the size of windows can be changed, the initial size of the window is used in preference to the lines value in terminfo. When the window is resized, the new size is reread. If the new size is greater than the initial size then the extra lines might not be used.

If you want to use the full depth of the window you might need to set LINES to the current depth of the window on some platforms.

Using LINES values that do not correspond to the actual depth of the window produces unexpected results.

Example

LINES=50
export LINES

M

MAINFRAME_FLOATING_POINT

Specifies the format to use for floating point data items. Possible formats are IBM hexadecimal and IEEE.

Syntax

MAINFRAME_FLOATING_POINT=fpstatus
export MAINFRAME_FLOATING_POINT

Parameters

fpstatus Which format to use for floating point data items. This must be one of:

true Specifies that IBM hexadecimal format floating point data items are to be used.
false Specifies that IEEE format floating point data items are to be used.

Setting MAINFRAME_FLOATING_POINT to anything other than true has the same effect as setting it to false.

The setting of this environment variable can be overridden by the NATIVE-FLOATING-POINT directive.

MF_ALIAS

Specifies program aliases. Each set (pair) is 16 characters long - 8 characters for the program-name, and 8 characters for the alias. You can specify up to 10 pairs. This list is searched first and thus can potentially override the built-in list. If not found, the built-in alias table is searched.

MF_AMODE31ONLY

Indicates that all programs are AMODE(31).

MF_CBLQDA

Determines if QSAM files are dynamically allocated when processing an OPEN I-O or OPEN EXTEND statement for an optional file (that is, a file opened using the SELECT OPTIONAL syntax in the FILE-CONTROL paragraph) or a file opened for OUTPUT (regardless of whether it is optional or not). Permissible values are OFF and ON; the default is OFF, which specifies that dynamic allocation is not permitted.

This is an emulation of the CBLQDA Language Environment (LE) run-time option.

When set to ON, and your JCL contains a misspelled or no DD statement for the file being opened, a temporary file is created as a result of the OPEN statement, and then deleted after the program has run. For optional files opened for I-O or for EXTEND, you receive a return code of 05; for files opened for OUTPUT, you receive a return code of 00.

This variable has no effect on VSAM applications or the JCL utility programs.

Note: For programs that use ESDS files and have this variable set ON, ensure that FILETYPE is set to 15 or 16; otherwise these files will be affected by the variable, and treated as QSAM files.

MF_CHARSET

Specifies the system character set (ASCII or EBCDIC).

MF_DUPJOBS

Enables jobs with identical names to run.

Values:

Y (Default)
N

MF_FALLTHRUCHECK

Specifies that MSS is to check that the main COBOL program ends by executing a GOBACK or STOP RUN.

Values:

y (default)
n

MF_JCL_AUDIT

Specifies that the audit log records audit information when a catalog entry is deleted.

Values:

DLET - Logs audit information each time an ESMAC/CAS utility deletes a catalog entry
DLEJ - Logs audit information each time a step in a JCL job deletes a catalog entry
DLET,DLEJ - Logs audit information each time either an ESMAC/CAS utility or a JCL job step deletes a catalog entry

MF_MFA

Specifies what dataset catalogs are to be searched.

Values:

ALL - Search for datasets first in the local catalog, and if not found, on the mainframe (default)
RJSE - Search for datasets in the local catalog only. No mainframe is performed.

MF_MVSJOB

Sets the number at which a job starts and finishes.

MF_MVSJOB=<lower value>{-|+}<upper value>

Where:

<lower value>: Number at which a job starts. Contains 7 digits - for example, 0000001
-: Sets the values but only on the first startup of the region.
+: Reset the values to these new ones each time the region is started.
<upper value>: Upper job number. Contains 7 digits - for example, 9999999

For example:

set MF_MVSJOB=0000010+0000100

This resets the values to start with job number 10 and run through to job number 100. When the upper limit has been reached you receive a message:

All job numbers in the range 0000010:0000100 are in use

At this point you need to remove some jobs from the spool - you can use the spool housekeeping functions to do this.

This environment variable can be used to enable a 7-digit Job number limit. If the <upper value> mentioned is greater than 99999, then 6+ digit job number support is enabled. The maximum value that can be set is 9999999.

Tip: To revert to 5-digit job number support, set MF_MVSJOB=<low number>+<high number>, where high number is less than 0099999, and ensuring that the + sign is used to separate the low and high values.

If a value set using this variable is not valid, the default values of <0001000>{-|+}<0099999> are set.

MF_NEWSPACE

Indicates whether SPACE is required for NEW datasets.

MF_PCRENAME_LAX

When an MVS dataset is renamed, the associated physical file is normally renamed only if it is in the Default Allocation Dataset Location. Set MF_PCRENAME_LAX to Y to enable physical files in other locations to be renamed if the cataloged name is changed.

MF_NODD

Specifies what action MSS is to take at run time if a job step uses a file that has not been allocated.

MF_RCCF

Enables Remote Job Step Execution (RJSE).

MF_ROOT_CERT

Enables the MF Directory Server process and any client applications to pick up the value of the root certificate file.

MF_SMS

Enables SMS support

MF_SPOOL_ARCHIVE_LOC

The base location for files archived as part of the spool housekeeping process, where the contents of the MVS SPOOL spool file are archived prior to deletion.

Syntax

MF_SPOOL_ARCHIVE_LOC=file-location
export MF_SPOOL_ARCHIVE_LOC

Values

file-location The file location.

MF_SPOOL_HK_LEX_SCAN

Determines if the MFELX* files associated with a job are also deleted when spool housekeeping is run.

Syntax

MF_SPOOL_HK_LEX_SCAN=Y|N
export MF_SPOOL_HK_LEX_SCAN

Values

Y The files are deleted.

N The files are not deleted.

Default

The default is Y.

MF_SPOOL_HK_OUTPRT

Determines if files from the Complete queue with a status of Output or Printed are also deleted when spool housekeeping is run.

Syntax

MF_SPOOL_HK_OUTPRT=value
export MF_SPOOL_HK_OUTPRTC

Values

Y Files from the Complete queue are deleted.

NFiles from the Complete queue are not deleted.

Default

The default is Y.

MF_SPOOL_HK_TESTDATE

Overrides the normal date for the spool housekeeping.

Syntax

MF_SPOOL_HK_TESTDATEC=YYYYMMDD
export MF_SPOOL_HK_TESTDATEC

Values

YYYYMMDD The date which is to override the normal date.

Default

If this variable is not set, the normal date for the spool housekeeping is used.

MF_SPOOL_HK_WRITE_PROFILES

Determines the creation of profile files (.PRO files) when a data set is archived.

Syntax

MF_SPOOL_HK_WRITE_PROFILES=Y|N
export MF_SPOOL_HK_WRITE_PROFILES

Values

Y Profile files are created.

N Profile files are not created.

Default

The default is Y.

MF_SYSLOGDSN

The Syslog Dataset name.

MF_UCC11

Enables emulation of UCC11, a third party add-on to the mainframe that affects data set disposition processing. If UCC11 is enabled, a data set disposition of NEW is accepted even if the data set already exists.

Values

y
n (Default)

MF_USESCA5

Specifies that the server should use version 5 of the Open Service Component Architecture.

Values:

ON (Default)
OFF

MF_USESCA7

Specifies that MSS accepts CA7 Scheduler control statements as comments rather than diagnosing them as errors.

Values:

ON (Default)
OFF

MFALLOC_LOC

The location of the default allocated dataset.

MFALLOC_PCFILE

When set to Y, which is the default, it will cause a catalogued file to be physically created if DSORG=PS is specified in the relevant DCB parameters.

MFALLOC_PROP

Rules for generated PC dataset names on allocation (that is, the default catalog PC DSN format).

MFAUDIT_LOGS

The location of audit files.

MFCODESET

Specifies which translation tables to use.

Values

On UNIX platforms (requires Micro Focus Enterprise Developer Unix Components):A pre-defined country code:

Important: To specify a Euro codeset, meaning that it includes the Euro symbol (€), prefix an "E" to the appropriate country code listed below. A country code with no "E" prefix indicates a non-Euro code.

Country Code (MFCODESET)	EBCDIC CCSIDs	Language
AUTOMATIC AUTO		Operating system default - sets country code based on CBL_GET_OS_INFO
DEFAULT		For a single-byte character set environment, 0437 (US English) selected; else 0081 (Japanese Katakana Extended) selected.
0031	37, 1140	Dutch
0033	297, 1147	French
0034	284, 1145	Spanish
0039	280, 1144	Italian
0043	273, 1141	German (Austrian)
0044	285, 1146	UK English
0045	277, 1142	Danish
0046	278, 1143	Swedish
0047	277, 1142	Norwegian
0049	273, 1141	German
0066	838	Thai Extended
0081†	930 (290, 300)	* Japanese Katakana Extended
0082	933 (833, 834)	*Korean
0086	13676 (836, 837)	*Simplified Chinese
0351	37, 1140	Portuguese
0358	278, 1143	Finnish
0437	37, 1140	US English
0500	500, 1148	International (Latin 1)
0886	937 (37, 835)	*Traditional Chinese
0930 †	930 (290, 300)	*Japanese Katakana Extended
0939 †	939 (1027, 300)	*Japanese Latin Extended
9122 †	9122 (290, 300)	*Japanese Katakana

Character sets marked with an asterisk (*) are capable of mixed single-byte and double-byte character conversion. EBCDIC CCSIDs in these rows indicate the mixed-byte CCSID first, followed by the single-byte, then double-byte Code Page Global Identifiers (CPGIDs) in parenthesis.

Other EBCDIC CCSIDs in parentheses reflect a 'non-Euro, Euro' pair for appropriate country codes.

For Windows and UNIX database applications accessing a UNIX database created with single-byte character sets 819 or 923, use the following table:

Country Code (MFCODESET)	EBCDIC CCSIDs	Languages
1140	37,1140	Dutch US English Portuguese
1141	273,1141	German (Austrian) German
1142	277,1142	Danish Norwegian
1143	278,1143	Swedish Finnish
1144	280,1144	Italian
1145	284,1145	Spanish
1146	285,1146	UK English
1147	297,1147	French
1148	500,1148	International (Latin 1)

A code between 2000 and 9999 (except 9122) corresponds to a user-defined translation table. User-defined tables are created using the Codecomp utility.

MFCSCFG

Specifies a configuration file to be used by the Client/Server Binding client program.

Syntax

MFCSCFG=filename
export MFCSCFG

Parameters

filename The name of the configuration file.

Example

MFCSCFG=/home/mydir/mfclisrv.cfg
export MFCSCFG

Comments

The value of MFCSCFG is overridden by any value defined in the command line. If neither of the above yields a filename, the default filename mfclisrv.cfg is assumed, and is searched for in the current directory. If that in turn is not found, the default settings for the configuration entries are used.

MFE.SMS

Enables SMS support.

MFEXTMAP

Location of a mapper file.

MFIMS_ACBDUMP_TIMESTAMP

Suppresses date/time stamp display in ACB report.

MFIMS_BMPCHKP

Returns a QC to a checkpoint call when it the call includes an IO area.

MFIMS_DIBSTAT_CODES

Specifies additional DIBSTAT return codes to be returned to EXEC DLI program.

MFIMS_DLI_OPT

Specifies DL/I call optimization flags.

MFIMS_DIAG

Enables IMS BTS format diagnostic tracing.

MFIMS_FLUSHTRACE

Flushes BTS trace file to disk after every write.

MFIMS_FP_DA

Bypasses keycheck on IMS Fastpath DB delete.

MFIMS_LOADMVS

Disables load of MVS support for IMS application programs.

MFIMS_PCBCALL

Allows a standalone EXEC DLI program to issue a PCB call.

MFJ_INPUTDS_ERROR

When set to N, this will cause IEBDG, IEBGENER, IEBCOMPR, and DFSORT and ICETOOL emulation to treat missing files as though they were present but empty.

MFJSABCODE

Determines the abend (abnormal end) code issued when MFJSERET=ABEND is in effect. If a Sort or Merge operation fails with an unrecoverable error, it will abend with a code between S001 and S063.

Syntax

MFJSABCODE=code
export MFJSABCODE

Parameters

code A decimal value between 1 and 99 representing the abend code to be issued.

Any specified value outside of the range 1 to 99 will result in an abend code of S00D being issued.

Default

By default, this environment variable is not set. If so, and if MFJSERET=ABEND is in effect, an abend S00D (decimal code 16) is issued when a Sort or Merge operation fails with an unrecoverable error.

Example

MFJSABCODE=77

This example results in abend code S04D being issued.

MFJSENGINE

Specifies which sort engine the utility MFJSORT is to emulate.

Syntax

MFJSENGINE=value
export MFJSENGINE

Values:

DFSORT Emulates DFSORT
SYNCSORT Emulates SYNCSORT

Example

Default

The default is DFSORT.

MFJSERET

If this environment variable is not set, an unsuccessful operation and its program will terminate with an unrecoverable error (return code 16). See also MFJSABCODE.

Syntax

MFJSERET=ABEND
export MFJSERET

Parameters

ABEND The operation will abend and its program will continue instead of terminating with an unrecoverable error (return code 16)

Default

By default, this environment variable is not set.

MFJSSTRICTSORT

Enables or disables the following mainframe behavior:

All JCL statements must contain a SYSOUT parameter, otherwise they will abend.
Modification of a ZD number with value 0 through INREC or OUTREC processing now keeps its sign value.
Records that are shorter than the output file's LRECL will be padded with low-values instead of spaces.
Input RECFM is identical to the output RECFM or OUTFIL RECFM (unless FTOV or VTOF/CONVERT has been specified), otherwise it errors with return code 16.

Syntax

MFJSSTRICTSORT=ON|OFF
export MFJSSTRICTSORT

Default

The default is OFF.

Example

MFJSSTRICTSORT=ON

MFJSTATS

For a COBOL sort not running under mainframe emulation, setting the environment variable MFJSTATS to ON creates a report containing statistics for the SORT that is displayed to SYSOUT. If a report file already exists for a previous SORT, the new statistics are appended to the end of the previous one.

If you are performing a COBOL sort using mainframe emulation, you can create a statistics report by modifying the JCL statement.

Syntax

MFJSTATS=switch
export MFJSTATS

Parameters

switch Switches report creation ON or OFF. The default is OFF.

MFJSWINDOW

Use this environment variable for Y2K compatibility, when two-digit year values are used.

Syntax

MFJSWINDOW=value
export MFJSWINDOW

Values

To set a sliding century window, set a value between 0 and 100. For example, a value of 80 would set a century window of 1931-2030 in 2011, 1932-2031 in 2012, and so on.

To set a fixed century window, set a value between 1000 and 3000. For example, a value of 1973 would set a century window of 1973-2072.

Default

The default is a sliding value of 80 when emulating DFSORT, and a default value of 0 when emulating SYNCSORT. A value of 0 equates to a century window, starting in the current year.

Comment

You can use this environment variable instead of the Y2PAST sort option.

Example

MFJSWINDOW=25

MFLECONFIG

Specifies a configuration file for Language Environment (LE) runtime options.

Syntax

MFLECONFIG=filename
export MFLECONFIG

Parameters

filename The file containing the LE runtime options you want to use.

MFLOCKING

Enables Locking Support

MFLOGDIR

Specifies a directory to be used by Client/Server Binding for log files.

Syntax

MFLOGDIR=dirname
export MFLOGDIR

Parameters

dirname The name of the directory for log files.

Example

MFLOGDIR=/home/mydir/logs
export MFLOGDIR

MFPLI_PRODUCT_DIR

The location of the Open PL/I installation. Used to find files needed for compiling and linking.

MFPRELOAD_USE

Calls MFPRELOAD to improve performance.

MFREXX_LSEQ_RECSIZE_MAX

Specifies the record length for the REXX EXECIO command when reading or writing a line sequential file that has been cataloged with a record length of zero.

Values:

Record length to use (Default = 255)

MFREXX_NOT

Specifies one or more characters to be used for the NOT operator in addition to REXX's default, which is "¬".

Values

One or more characters for each operator; each character you specify is used in addition to the default operator. Each additional character must be defined within single or double quotes, or in hexadecimal. Separate multiple characters with a space or a comma.

MFREXX_OR

One or more characters to be used for the OR operator in addition to REXX's default, which is "|".

Values

One or more characters for each operator; each character you specify is used in addition to the default operator. Each additional character must be defined within single or double quotes, or in hexadecimal. Separate multiple characters with a space or a comma.

MFSUB

Specifies whether to use SUBI or ASUBI.

Values

SUBI
ASUBI

MFSYSCAT

The location of the JES system catalog.

MFSYSCATDIR

The location of the system catalog directory.

MFTRACE_ANNOTATIONS

The location of the trace files.

MFTRACE_CONFIG

The location of the CTF configuration file.

MFTRACE_LOGS

The location of the CTF log files.

MFTSO_DEBUG

Controls the display of debug messages.

MFUSER

The default User ID.

MFUSERCAT_LOC

User catalog location

MQSERVER: The location of a WebSphere MQ Server installation.

MULTMFENTMAP: Specifies whether special characters such as < and & are replaced with the equivalent HTML entities (for example < and &).

O

OOSW: OO run-time switches.

P

PATH

Specifies the directories to be searched by all UNIX programs, including the runtime system, when finding executables to be run.

Syntax

PATH=pathname[:pathname]...
export PATH

Parameters

pathname A directory to search for executables.

Example

PATH=$COBDIR/bin:$PATH
export PATH

PROCLIB: When set to ON and under a mainframe emulation, a file status of 37 is returned when you open an existing VSAM file for OUTPUT and the file has or previously had some data written to it, or if the file format is different from the file on disk. The default for this variable is OFF.

R

RANDOM: If using SSL connections, externally generated random data that is stored as a numeric value in the RANDOM variable will be inserted into the initial salt value used to generate temporary key pairs used in SSL hand-shaking. The RANDOM value will only form part of the initial salt value and is an aid to generating more randomness and not an essential requirement.

S

SORTCOMPRESS

Tells the system whether or not to execute a compression routine on each record to be sorted.

Syntax

SORTCOMPRESS=5
export SORTCOMPRESS

Parameters

5 This is the only value that you can supply. It allows for run-length encoding of sort records, resulting in much better performance when records contain multiple repeated characters.

Comments

This variable is recommended if the sort records contain many single repeated characters, for example, multiple spaces, as it can be very effective in improving memory usage and therefore sort performance.

Example

SORTCOMPRESS=5
export SORTCOMPRESS

SORTSCHEME

Activates a sortscheme. Use in conjunction with SORTSPACE for improved performance.

Syntax

SORTSCHEME=1
export SORTSCHEME

Values

SORTSCHEME=1 - this is the only valid value for the environment variable. See SORTSPACE for more information.

SORTSPACE

The amount of memory to be allocated to internal workspace for SORT operations. This can be specified in different formats: for example, you could specify 64M, 2G, and 1000000 to give sort memory areas of 64 Megabytes, 2 Gigabytes and 1000000 bytes respectively.

Syntax

SORTSPACE=n[K|k|M|m|G|g]
export SORTSPACE

Parameters

n[K|k|M|m|G|g The amount of memory to be allocated to internal workspace for SORT operations. K or k indicates kilobytes, M or m indicates megabytes and G or g indicates gigabytes. No letter indicates bytes. Defaults to 1 megabyte.

Comments

A larger value for SORTSPACE will generally result in a faster sort. However, if you specify a value that exceeds the capacity of main memory in your computer, such that the operating system has to page memory in and out, performance will be degraded.

Example

SORTSPACE=1024K
export SORTSPACE

SORTTEMPSPACE

Specifies the amount of memory to be allocated to temporary workspace for SORT operations.

Syntax

SORTTEMPSPACE=n[K|k|M|m|G|g]
export SORTTEMPSPACE

Parameters

n[K|k|M|m|G|g] The amount of memory to be allocated to temporary workspace for SORT operations. K or k indicates kilobytes, M or m indicates megabytes and G or g indicates gigabytes. No letter indicates bytes. 32 megabytes is the lowest amount of memory that can be allocated.

Comments

The memory allocation strategy used by SORT can be adjusted through use of SORTTEMPSPACE, which generally improves performance in systems suffering from memory fragmentation.

Example

SORTTEMPSPACE=250MB
export SORTTEMPSPACE

SORTTYPE

Defines the sort type.

Syntax

SORTTYPE=2
export SORTTYPE

Values

SORTTYPE=2 Forces SORT to use the file handler, so that format modifications are picked up from the extfh.cfg file.
Not setting this variable means that SORT will try to use CBL_ routines to read and write files to improve performance.

Note: 2 is the only valid value for this environment variable.

SSLDIR

If using SSL connections, this value specifies the generic location of the system's OpenSSL directory.

STEPLIB

The paths for Loader input load-members .390 files (must contain SYSLMOD) .

Note: For this environment, you can specify multiple paths, each separated by a colon.

T

TERM

Defines the type of terminal being used.

Syntax

TERM=name
export TERM

Parameters

name The name of the terminal in the terminfo database.

Example

TERM=at386
export TERM

TERMINFO

Specifies the directory to be searched by all UNIX programs, including the runtime system, for the UNIX system terminfo database.

Syntax

TERMINFO=pathname
export TERMINFO

Parameters

pathname The name of a directory that contains the UNIX system terminfo database.

Comments

The UNIX system terminfo database is used by all UNIX applications that need to use a terminal. However, COBOL applications tend to make much fuller and sophisticated use of the terminal and require a fuller terminfo description than is required by typical UNIX applications such as vi. Some terminal capabilities, such as those set during the initialization of the terminal to control the use of function keys, commonly conflict with the needs of typical COBOL applications. In such cases, the terminal information required by COBOL can be stored in a separate terminfo database and referenced using COBTERMINFO.

TMPDIR

Specifies a directory in which to store temporary files in place of the UNIX system default.

Syntax

TMPDIR=pathname
export TMPDIR

Parameters

pathname The directory used by UNIX applications for any temporary work files. Temporary work files can be created by COBOL utilities such as Cob or by the runtime system when it executes statements such as SORT. If you do not specify a directory, the system default directory is used.

Comments

You might need to use this environment variable if the runtime system needs to page data to disk when creating heaps or sorting.

TX_MQTRACE: Enables tracing in dfh0mqis for WebSphere MQ calls.

TX_TN3270_FORCE_ALT: Enables you to use a screen size other than the default when using a TN3270 terminal emulator.

TXFILEP: The location of Micro Focus VSAM files.

TXMAPP: The location of the BMS load module.

TXRDTP: The location of MSS resource definition (RDO) files.
TXTRANP: The location of the CICS application object files.

U

USER: Default user name.

V

VSE_STARTUP_CFG: The location of the VSE JCL configuration file
